Autoclave SX-700

$9,850.40

  • Small Footprint + Large Loads = Save Time, Space and Effort
  • 69-Liter capacity
  • Accommodates up to 3 stackable stainless-steel baskets for maximum capacity loads (includes 2 baskets).
  • Bulk / multiple unit discounts are available for this item; please inquire using the contact form for pricing.

SKU: T70.000.00 Category:

  • Description
  • Specification

Fast and compact lab autoclave sterilizer.

Small footprint and maximum capacity in the least amount of space. Fits any lab!

Rapid Cooling Action

TOMY SX-700 Lab Autoclave comes standard with a dual fan system, which reduces the cooling time by 42% compared to non-fan-equipped autoclaves. Thus, shortening overall operation time and reducing the possibility of burns.

Easy installation

Just plug it in and add water! Whereas some lab autoclaves need plumbing or vacuum connections, Tomy Autoclaves are simple to install.

Intuitive operation

Because of a well-designed LED display, the TOMY SX-700 Lab Autoclave is easy to monitor. The foot-pedal assisted mechanical lid makes for easy opening. And wheels allow for effortless movement and storage.

5 Convenient Sterilization Settings

First, a Liquid Sterilizing Course which helps prevents boiling over. Second is the normal Sterilizing Cycle. Next the Sterilizing–Warming Course prevents coagulation, hardening, or freezing of culture media after the sterilization ends. Then the Heating–Warming Course, which is convenient for heating and dissolving culture media. Last, a Memory Recall setting, which allows you to repeat previous settings.

Space-Saving

The main body of the SX-700 autoclave is compact because of the vertical design. Vertical autoclaves are ideal for maintaining high capacities in a compact lab setting. In addition, installation space at the side of the autoclave is not required, as compared to autoclaves using a slide-open lid.

Designed to be reliable and simple

Made of high quality, durable materials. Because TOMY focuses on quality, we help create the best user experience possible, with minimal maintenance or downtime.
View Specifications
chamber-capacity

Chamber Capacity

69 L

Weight

159 lbs

Max Temperature

135 °C

Max Operating Pressure

0.25 MPa

Width

18.5”

Depth

20.8”

Height

39.5”

Power Source

AC 207-253 V 13A (230V recommended)
Details
Operating Temperature RangeSterilizing105 - 135°C (0.019 - 0.212 MPa)
Heating45 - 104°C (0 - 0.015 MPa)
Warming45 - 95°C
Maximum Operating Pressure0.25 MPa
TemperatureDisplayDigital
Pressure GaugeDisplayAnalog
Display Range0 - 0.4 MPa
Heat Source3 kW electric heater
Safety Device• Water level sensor • Current leakage breaker • Lid interlock • Over-heat prevention • Over-pressure prevention • Open temperature sensor detection • Safety valve
Time
DisplayDigital
Display RangeSterilizing0:00 - 9:59, 0 - 99 hours, 0 - 999 min. (0:00 - 9:59, 10 - 99 hours changeable)
Heating
WarmingVariable: 0 - 99 hours
Effective Chamber Dimensionsφ360 x 675 mm
Chamber CapacityEffective internal volume: 69 L, Internal volume: 79 L
Chamber MaterialSUS304
Dimensions (mm)470 (W) x 528 (D) x 1003 (H) mm (With protruding: 625 D)
Weight72 kg
Required Power SupplyAC 207-253 V 13A (230V recommended) Requires NEMA6-15P type power plug
Power Consumption (calorific value)3.0 kW (2580 cal/h)
Environmental Conditions

When operating the autoclave, observe the environmental conditions given below.

Ambient temperature: 10 to 35°C

Atmospheric pressure: 860 to 1060 hPa

Relative humidity: 30 to 85%

Maximum gradient: 2

AccessoriesStainless baskets 2 (φ345 x 181 mm)
• Chamber bottom Plate (1) • Caster stoppers (4) • Operator's Manual (1) • Clear folder (for storing the operation manual) (1) • Screw (for attaching the clear folder) (1) • Warranty card (1) • Customer card (1) • Inspection Sheet (1)
